High Reliability SMD Tantalum Capacitor 10uF 16V A CASE 1206c
Brief Introduction
•Epoxy molded encapsulation, Chip, Easy for Integration, Heteropolarity;
•Small in size , Light in Weight , Stable in electrical &storage performances. Long life-span. High reliability ;
•Applying in Satellite, Telecommunications , DV, Computer , such Electrical Equipment with SMT DC& Impulse Circuits
•Operative Standard: QJ/PWV109-2003;
Features
•Operating Temperature Range: -55℃＋ 125℃(when > 85℃, with rated voltage derating)
•Rated Voltage, Category Voltage, Nominal Capacitance: See Table 2
•Capacitance Tolerance: K:土10%; M:土20%;
•DC Leakage at 25℃ ;㏒≤0.01CRUR(µA) or 0.5uA ( Choose the greater one)
•Dissipation Factors ( tg6 ) at 25℃; Not exceed the parameter in Table 2
- ESR : Not exceed the parameter in Table 3;
- Dimensions: See Table 1& Figure; Not exceed the parameter in Table 2
Table 1 Dimensions
| CASE CODE | EIA | EIA | L | W1 | H | S | W2 |
| A | 1206 | 3216-16 | 3.20±0.20 | 1.60±0.20 | 1.60±0.20 | 0.80±0.20 | 1.20±0.20 |
| B | 1210 | 3528-19 | 3.50±0.20 | 2.80±0.20 | 1.90±0.20 | 0.80±0.20 | 2.20±0.20 |
| C | 2312 | 6032-25 | 6.00±0.20 | 3.20±0.20 | 2.50±0.20 | 1.30±0.20 | 2.20±0.20 |
| D | 2917 | 7343-28 | 7.30±0.20 | 4.30±0.20 | 2.80±0.20 | 1.30±0.20 | 2.40±0.20 |
| E | 2917 | 7343-43 | 7.30±0.40 | 4.30±0.40 | 4.10±0.40 | 1.30±0.20 | 2.40±0.20 |
| V | 2924 | 7361-36 | 7.30±0.40 | 6.10±0.40 | 3.60±0.40 | 1.35±0.20 | 3.00±0.20 |
| W | 2924 | 7361-41 | 7.30±0.40 | 6.10±0.40 | 4.10±0.40 | 1.35±0.20 | 3.00±0.20 |
| G | 3329 | 8575-45 | 8.50±0.40 | 7.50±0.40 | 4.50±0.40 | 1.80±0.20 | 4.50±0.20 |
| S | 4335 | 11090-45 | 11.0±0.40 | 9.00±0.40 | 4.50±0.40 | 1.50±0.20 | 7.00±0.20 |
| T | 4349 | 110125-55 | 11.0±0.40 | 12.5±0.40 | 5.50±0.40 | 1.50±0.20 | 10.5±0.20 |
Part No: TMCT02-106K16VTA
Part Number Naming Rule:
| TMCT | 02 | _ | 106 | K | 16V | T | A |
| Product Category | Sub-Series | | Capacitance | Tolerance-10% | Voltage | Package:Tape&Reel | Case Size |
Specification Table 2
| Rated Voltage (V) | Capacitance (uF) | Case Code | Leakage Current(uA) | DF(tgδ) @ +25 ℃, 100Hz | ESR@+25 ℃, 100KHz (mΩ) |
| 16 | 10 | A | 1.6 | 6 | 3 |
Note: 1. Ur is Rated voltage Cr is normal capacitance
2. Pls don’t test above parameters with the universal meter
2. Capacitance and DF measured at: U_=2.2-1.00V,U~=1.0-0.50VV ( Voltage) Frequency :(100±5)Hz
3. Need decrease the rated voltage to use when environmental temperature is more than 85 ℃ (DCL measuring conditions: Applying rated voltage, the charging interval can exceed 5min.)
Product Tags:
|
|
High Reliability SMD Tantalum Capacitor 10uF 16V A CASE 1206 Images
|
